Display the patient’s Dicom files on a separate monitor(DICOM Web Viewer)
Parameter data storage (TREND) for 96 hours
Storage and displaying 720 alarms including ECG display at the time of alarm for each patient (Alarm Recall)
Capability to store graphic data waveforms(Disclosure) for 48-hours and store on data server permanently
Optional displaying of ECG,SPO2,IBP1,IBP2,CO2,RESP signals
Optional displaying of parameters
Visual and auditory alarms
Usage of more pages
Laser printer instead of thermal recorder
|
General |
|
|
CE marking |
Computer |
|
SAHAND Performance |
|
|
Display |
|
|
20″/ 19” / 19W” / 17” color TFT LCD with resolution of 1280/2560 * 1024 |
Size |
|
1 or 2 sets (optional) |
Number of displays |
|
ECG (I, II, III, aVR, aVL, aVF, V), SpO2, Dual IBP, Resp/Co2 (All freezable) |
Waveforms |
|
12.5, 25, 50 mm/s |
Signal sweep |
|
HR, SpO2, Dual Temp, DT, NIBP, Dual IBP, RESP /CO2 (EtCo2, FiCo2, AWRR) |
Numeric Parameters |
|
Mouse with PS/2 or other standard interfacings / Touch screen |
Operation Method |
|
Network |
|
|
Digital, Full Duplex with TCP/IP protocol, LAN |
Wired network |
|
10 M/100M Base-T, Ethernet 802.3, RJ45 interface |
|
|
Supports manufacturer’s patient care monitors |
Connection |
|
Up to 16 bedside monitors |
|
|
Remote monitor control |
|
|
Bedside settings through the Central and vice versa |
|
|
Alarm |
|
|
Physiological, Technical, Systemic |
Alarm types |
|
High, Moderate, Low |
Alarm levels |
|
Audible-Visual alarm |
Alert |
|
Review |
|
|
Review of 96 hours Trend, Graphic and Tabular |
Trend |
|
48 hours store and review of ECG waveform |
Disclosure |
|
HR, RR, SpO2, T1, T2, ST, EtCo2, FiCo2, Dual IBP (SYS,DIA,MAP) |
Trend or Disclosure data |
|
Review of 1000 NIBP measurements |
NIBP List |
|
Review of 720 Alarm events |
Alarm List |
|
Managing Patient information |
Patient info |
|
Storing 100 HR alarms |
Alarm History |
|
Managing record requests |
Recorder History |
|
Bed view(Optional) |
|
|
All waveform and parameters of one Bed in larger size |
|
|
Recorder (Optional) |
|
|
Saadat external thermal recorder |
Model |
|
120 (W)* 96 (H) * 165 (D) (mm) / 425 g (approximately) |
Size / Weight |
|
12.5, 25, 50 mm/s |
Printing speed |
|
57 mm |
Paper width |
|
1 waveform (ECG) |
Trace |
|
Fixed time/Continuous recording, Automatic / Manual Alarm recording, NIBP List recording, Trend recording, Disclosure recording, Freeze recording, Periodic recording. |
Recording Type |
