Product features
Design:
- Horizontal, radial split volute casing
- Single-stage, single-suction
- Single or double volute for branch sizes larger than 80 mm
- Casing heating available
- Usually mechanical seal
- One-piece heavy duty bearing bracket with oil/grease lubricated antifriction bearing
- Air cooling (with fan) of the bearing, however also water cooling possible
Features:
- Fully interchangeable modular elements for various pump sizes to minimize spare stock keeping Foot mounted single stage
| Type of bearing | Ball and Rolling element bearings |
| Casing partition | Radially split |
| Casing material | Table H-1 of API610 |
| Drive frequency | 50 Hz /60 Hz |
| Type of drive | Electric motor , Diesel Engine |
| Drive voltage | Low voltage |
| No. of Impeller entries | Single entry |
| Impeller material | Table H-1 of API610 |
| Type of installation | Long-coupled |
| Type of coupling | Direct |
| Type of lubrication | Grease / Oil |
| Max. permissible fluid temperature | 3300 °C |
| Min. permissible fluid temperature | -80 °C |
| Nozzle position | End suction / Top discharge |
| Pull-out design | Yes |
| Pump set location | Dry installed |
| Shaft material | Table H-1 of API610 |
| Suction characteristics | Non-priming |
| Type of casing | Volute casing |
| Type of Impeller | Radial, Closed, Multi-vane Impeller |
| Maximum head | 300 m |
| Minimum head | 9 m |
| Installation position | Horizontal |
| Shaft seal type | Mechanical / Soft Packing seal |
| Main applications | Industry and process Engineering, Energy |
| Maximum discharge-side pressure | 25 bar |
| Maximum drive rating | 220 kW |
| Type of installation | Stationary |
| Maximum flow rate | 3500 m³/h |
| Minimum flow rate | 2 m³/h |
Applications:
Pumping of:
- Hydrocarbons, cold or hot
- Chemicals, neutral and aggressive liquids
- Seawater
Exploitation:
- Cryogenic Engineering
- Offshore Industries
Exploitation:
- No cooling water pipe-work
- No cooling water consumption
- No increased bearing heating
- Few bearing checks required
- Small shaft deflection
- Long rated life of mechanical seal due to low radial thrust
- Low cost for pipe-work support
- Low spare part need
