Optical Characteristics
parameter | 20W | 30W | 40W | 60W |
light source led | SMD LED | SMD LED | SMD LED | SMD LED |
number of leds in the module pcs | 36 | 54 | 72 | 108 |
luminous flux lm | 2300 | 3450 | 4600 | 6900 |
luminous efficiency lmw | 115 | 115 | 115 | 115 |
color temperature k | 3000 , 4000, 5000, 6500 | 3000 , 4000, 5000, 6500 | 3000 , 4000, 5000, 6500 | 3000 , 4000, 5000, 6500 |
color rendering index | 85 | 85 | 85 | 85 |
sdcm initial and value | 5SDCM | 5SDCM | 5SDCM | 5SDCM |
photometric code | 730/559 , 740/559 , 750/559 , 765/559 | 730/559 , 740/559 , 750/559 , 765/559 | 730/559 , 740/559 , 750/559 , 765/559 | 730/559 , 740/559 , 750/559 , 765/559 |
lumen maintenance code | 9 | 9 | 9 | 9 |
Mechanical characteristics
parameter | 20W | 30W | 40W | 60W |
ingress protection ip | IP42 | IP42 | IP42 | IP42 |
body material | Aluminum | Aluminum | Aluminum | Aluminum |
Diffuser Material | PMMA | PMMA | PMMA | PMMA |
body coating | Electrostatic powder painting | Electrostatic powder painting | Electrostatic powder painting | Electrostatic powder painting |
weight kg | 1.75 | 2.3 | 3 | 4.3 |
dimension (mm) | L570W60H78 | L850W60H78 | L1120W60H78 | L1700W60H780 |
General Characteristics
rated ambient temperature tq related to performance for the luminaire | 25 |
working temperature range °c | 45+ ~ 20- |
maximum allowed humiding % | 90 |
rated median useful life l 70 b 50 hrs | 50000 |
rated abrupt failure value % | 15 |
Product code
power | 20W | 30W | 40W | 60W |
code | 377020 | 377030 | 377040 | 377060 |
Global standards
IES LM – 80 | Measuring Luminous Flux and Color Maintenance of LED Packages, Arrays and Modules |
